NVIDIA Mellanox OSFP Solutions

400G and 800G OSFP Compatibles for NVIDIA Network Infrastructure

As organizations continue to grow, they must take advantage of bandwidth-intensive applications like artificial intelligence, the Internet of Things (IoT), and advanced analytics. These applications require high bandwidth and low-latency connectivity to work optimally. Legacy infrastructure and small circuits simply can’t keep up with today’s demand. OSFP (Octal Small Form-factor Pluggable) has become a frontrunner in the latest 400/800G capability with options to sustain this high-speed requirement as well as features for connecting to lower existing speeds and network topologies. Advance your network with GigaTech Products NVIDIA Mellanox compatible OSFP transceivers to support 400G/800G speeds required for a high-performance AI GPU infrastructure.

MMA4Z00-NS400-GT

Single Port Transceiver, 400Gbps, NDR, OSFP, MPO12 APC

850nm MMF 50m, Flat Top NVIDIA Compatible

MMA4Z00-NS-GT

Twin Port Transceiver, 800Gbps, 2xNDR, OSFP, 2xMPO12 APC,

850nm MMF 50m, Finned NVIDIA Compatible

Features:

  • Four Parallel Lanes Allow for Direct 400G Connection or Breakout to Lower Bandwidth Applications
  • 400GbE data rate
  • 4x 106.125Gbps data rate per channel
  • MPO/MTP-12 APC MMF Connector
  • Hot-pluggable OSFP footprint
  • Up to 100M over OM4
  • Eight Parallel Lanes Allow for Direct 800G Connection or Breakout to Lower Bandwidth Applications
  • 800GbE data rate
  • 8x 106.125Gbps data rate per channel
  • Dual MPO/MTP-12 APC MMF Connector
  • Hot-pluggable OSFP footprint
  • Up to 100M over OM4

Benefits

  • Compliant with InfiniBand NDR End-to-End Systems
  • Verified for 100% compatibility with all intended NVIDIA Mellanox devices
  • Compliant with OSFP MSA, IEEE 802.3ck and Class 1 Laser Safety, with DDM Support

MMA4Z00-NS400-GT Breakout Options

MMA4Z00-NS400-GT

1x MPO-12 APC 400G Link

MMA4Z00-NS400-GT

Direct Connection between MMA4Z00-NS400-GT OSFP SR4 Transceivers for 400G Connectivity

MMA4Z00-NS400-GT
to ConnectX7 NIC

2x MPO-12 APC 400G Link

MMA4Z00-NS-GT

The OSFP SR8 Transceiver Supports 2x 400G OSFP SR4 Breakout Capability

MMA4Z00-NS-GT Breakout Options

MMA4Z00-NS-GT

2x MPO-12 APC 800G Link

MMA4Z00-NS-GT

Direct Connection between OSFP SR8 Transceivers for 800G Connectivity

MMA4Z00-NS400-GT
to ConnectX7 NIC

2x MPO-12 APC 400G Link

MMA4Z00-NS-GT

The OSFP SR8 Transceiver Supports 2x 400G OSFP SR4 Breakout Capability

Applications:

Data Center

Infiniband HDR

400G Ethernet

800G Leaf-Spine NVIDIA Implementation

Core

Spine

Leaf

Server

800G Switch to Server Implementation Diagram

Integration schematic featuring NVIDIA Quantum-2 MQM9790 switch utilizing MMA4Z00-NS-GT in 800G capacity as it integrates to MMA4Z00-NS400-GT via 400G ConnectX-7 Server application.

Never Sourced. Never Recycled.

All components in GigaTech Product optics are manufactured under the same roof and represent the gold standard for reliability and consistency in performance. This vertical manufacture chain allows GigaTech to avoid unnecessary variances in transceiver casing or laser quality often found with online resellers who source their components from an ever changing vendor list. The transceiver is guaranteed to be built from A-Stock never used components overseen by GigaTech Products,

Rigorous Testing & Standards Compliance

The quality and standards of our hardware is one the base foundations of GigaTech Products. All of our components comply with MSA (Multi-Source Agreement) output standards and, in many cases, excel beyond those certification standards. Every transceiver we produce is tested on active network devices to ensure they comply with OEM equipment and are verified to be plug-and-play and do not require work arounds.
